PRODUCT
Rubber sheet gasket SBR roll black material 1.3g/cm3
Reference Standard: ASTM standard
Quality Certification: SGS RoHS2.0 REACH
Thickness: 1mm-100mm
Specification (W/L):
Width: Standard 1mtrs 1.2mtrs 1.4mtrs 1.5mtrs 1.6mtrs 1.8mtrs 2.0mtrs
Length: Standard 5mtrs 10mtrs 15mtrs 20mtrs. Available upon request
Color: Black
Packing Information: Regular / Up to your choice
Packed with plastic film.
Packed with plastic film and with PP woven bag.
Wooden pallet.
According to the customer request, fixed-length or heavy package.
Product Supply Form: Sheet or Plate
Get more information:
Email: info@chn-rubber.com
P .H & Wechat: 008615222735180
Discover the dependable performance of our SBR (Styrene-Butadiene Rubber) Flat Rubber Sheet. This high-quality rubber sheet material is engineered for a multitude of general-purpose applications, offering an excellent balance of durability, flexibility, and value. Supplied in convenient sheet form, it's ready for immediate use or easy fabrication into custom parts.
As experienced sheet gasket suppliers, we understand the need for reliable and consistent materials. This SBR sheet provides a solid foundation for cutting gaskets, creating protective pads, lining surfaces, and much more. Its inherent properties make it a go-to choice for industrial maintenance, workshops, and DIY projects.
KEY FEATURES
- Durable General-Purpose Material: SBR offers good resistance to abrasion, impact, and tearing, making it suitable for demanding physical applications.
- Excellent Flexibility: This rubber sheet material conforms well to surfaces and is easily cut or punched into desired shapes, ideal for gasket making.
- Convenient Sheet Format: Supplied as a flat rubber sheet, it's easy to handle, store, and cut precisely without the need to unroll large sections. Perfect for smaller jobs or specific pre-cut requirements.
- Consistent Properties: Manufactured for reliability, ensuring consistent thickness and performance across the sheet.
- Specific Gravity: Features a specific gravity of approximately 1.3 g/cm³, indicating a solid, relatively dense composition suitable for various industrial uses.
- Cost-Effective Solution: Provides robust performance at an economical price point compared to more specialized elastomers.
SBR RUBBER SHEET PERFORMANCE & SPECIFICATIONS
| SBR RUBBER SHEET TECHNICAL PARAMETERS | ||||||||
| Code | Specific Gravity | Hardness (+/-5) | Tensile Strength | Elongation at Break | Colour | Finish Type | ||
| g/cm³ | Shore A | Mpa | (min） % | |||||
| STANSDARD | ASTM D397 | ASTM D2240 | ASTM D412 | ASTM D412 | --- | --- | ||
| ZXZRS20101S | 1.3+/-0.05 | 55 | 8 | 400 | Black | Smooth in both sides OR 1/2 With sides cloth OR 1 side With anti-slip texture | ||
| ZXZRS20201S | 1.3+/-0.05 | 55 | 8 | 400 | Red | |||
| ZXZRS20401S | 1.3+/-0.05 | 55 | 8 | 400 | Green | |||
| ZXZRS20001S | 1.3+/-0.05 | 55 | 8 | 400 | Customized production according to demand | |||
| Note: 1MPa =10.2 Kg/cm² 1N/mm =1.02 Kg/cm | ||||||||
| SPECIFICATION | ||||||||
| Item | Thickness | Width | Length | Insertion | Weight | |||
| mm | m | m | Material | Layers | KGS/m² | LB/ft² | ||
| 1 | 1 | Standard width | 5m/10m/15m/20m | Nylon canvas / Mesh fabric / Nylon mesh fabric / Encrypted canvas | / | 12.48 | 2.56 | |
| 2 | 1.5 | Standard width | 5m/10m/15m/20m | / | 20.28 | 4.15 | ||
| 3 | 1.7 | Standard width | 5m/10m/15m/20m | 1PLY | 23.40 | 4.79 | ||
| 4 | 2 | Standard width | 5m/10m/15m/20m | 1PLY | 28.08 | 5.75 | ||
| 5 | 3 | Standard width | 5m/10m/15m/20m | 1PLY | 43.68 | 8.95 | ||
| 6 | 4 | Standard width | 5m/10m/15m/20m | 1PLY | 59.28 | 12.14 | ||
| 7 | 5 | Standard width | 5m/10m/15m/20m | 2PLY | 74.88 | 15.34 | ||
| 8 | 6 | Standard width | 5m/10m/15m/20m | 3PLY | 90.48 | 18.53 | ||
| 9 | 8 | Standard width | 5m/10m/15m/20m | 4PLY | 121.68 | 24.92 | ||
| 10 | 10 | Standard width | 5m/10m/15m/20m | 5PLY | 152.88 | 31.31 | ||
| 11 | 12 | Standard width | 5m/10m/15m/20m | 8PLY | 184.08 | 37.70 | ||
| 12 | 15 | Standard width | 5m/10m/15m/20m | 10PLY | 230.88 | 47.28 | ||
| 13 | 20 | Standard width | 5m/10m/15m/20m | ≥10PLY | 52.00 | 10.65 | ||
| 14 | 25 | Standard width | 5m/10m/15m/20m | ≥10PLY | 65.00 | 13.31 | ||
| 15 | 30 | Standard width | 5m/10m/15m/20m | ≥10PLY | 78.00 | 15.97 | ||
| 16 | 50 | Standard width | 5m/10m/15m/20m | ≥10PLY | 130.00 | 26.62 | ||
* Tabulated weight values are provided for informational purposes only. As dimensional specifications of rubber sheets are fully customizable per project requirements, actual weights may vary accordingly. For precise weight calculations tailored to your application, please submit specific technical parameters to our engineering team.
* Please ensure the product meets your application specification prior to order placement.
Insertion materials:
 |
 |
 |
 |
| Nylon canvas | Mesh fabric | Nylon mesh fabric | Encrypted canvas |
TARGET APPLICATIONS
The flat rubber sheet format makes this SBR particularly well-suited for:
- 1. Custom Gasket Cutting: Easily create seals for water, air, and low-pressure applications (Note: Not recommended for oils, fuels, solvents, or strong chemicals). As trusted sheet gasket suppliers, we ensure this material meets general sealing needs.
- 2. Surface Protection: Use as liners for workbenches, tool drawers, or shelves to prevent scratches and absorb impacts.
- 3. Vibration Dampening: Create simple anti-vibration pads for light machinery or appliances.
- 4. Shims and Spacers: Cut precise pieces for alignment or filling gaps.
- 5. DIY & Crafting: A versatile material for numerous home or hobby projects requiring a resilient rubber.
