PRODUCT
5mm Rubber gasket sheet 1.6g/cm³ black SBR material
Whatsapp & P.H: 008615222735180
Email: info@chn-rubber.com
1. Material: 100% recycled rubber
2. Thickness:1mm-100mm
3. Width: 3m max
4. Length: 10m/roll 20m/roll or as your request
5. Gravity: 1.6g/cm3
6. Hardness:65±5
7. Tensile strength: 2.5Mpa
8. Elongation: 180%
9. with or without fabric reinforcement
5mm Rubber gasket sheet technical parameters
| Thickness mm | Gravity | width M | weight KGS/㎡ | Reinforcement |
| 1 | 1.6 | 1m/1.2m/1.4m/1.5m/1.6m/1.8m/2m | 1.6 | / |
| 1.5 | 1.6 | 1m/1.2m/1.4m/1.5m/1.6m/1.8m/2m | 2.4 | / |
| 1.7 | 1.6 | 1m/1.2m/1.4m/1.5m/1.6m/1.8m/2m | 2.72 | 1ply |
| 2 | 1.6 | 1m/1.2m/1.4m/1.5m/1.6m/1.8m/2m | 3.2 | 1ply |
| 3 | 1.6 | 1m/1.2m/1.4m/1.5m/1.6m/1.8m/2m | 4.8 | 1ply |
| 4 | 1.6 | 1m/1.2m/1.4m/1.5m/1.6m/1.8m/2m | 6.4 | 1ply |
| 5 | 1.6 | 1m/1.2m/1.4m/1.5m/1.6m/1.8m/2m | 8 | 2ply max |
| 6 | 1.6 | 1m/1.2m/1.4m/1.5m/1.6m/1.8m/2m | 9.6 | 3ply max |
| 8 | 1.6 | 1m/1.2m/1.4m/1.5m/1.6m/1.8m/2m | 12.8 | 4ply max |
| 10 | 1.6 | 1m/1.2m/1.4m/1.5m/1.6m/1.8m/2m | 16 | 5ply max |
| 12 | 1.6 | 1m/1.2m/1.4m/1.5m/1.6m/1.8m/2m | 19.2 | 8ply max |
| 15 | 1.6 | 1m/1.2m/1.4m/1.5m/1.6m/1.8m/2m | 24 | 10ply max |
5mm Rubber gasket sheet factory photo
 |
5mm Rubber gasket sheet descriptionOur 5mm rubber gasket sheet is made of SBR raw material vulcanized at high temperature to form a sheet rubber sheet. The biggest advantage of this rubber is that it is wear-resistant and durable, and can play the best role in basic applications, and the price is beautiful. |
If you are looking for a reliable and durable rubber gasket sheet, then you can't go wrong with a 5mm rubber gasket sheet. This material is perfect for a variety of applications, and it will provide a superior seal against fluids and other materials. You can count on this material to hold up against extreme temperatures and pressures, and it will resist tearing and abrasion. With a 5mm rubber gasket sheet, you can be confident that you are getting a high-quality product that will provide years of reliable service.
