PRODUCT
Green 1.7g/cm³ thickness roll styrene-butadiene rubber material
Reference Standard: ASTM standard
Quality Certification: SGS RoHS2.0 REACH
Thickness: 3mm; Thickness over 15mm, available in sheet form
Specification (W/L):
Width: Standard 1mtrs 1.2mtrs 1.4mtrs 1.5mtrs 1.6mtrs 1.8mtrs 2.0mtrs
Length: Standard 5mtrs 10mtrs 15mtrs 20mtrs. Available upon request
Color: Green
Packing Information: Regular / Up to your choice
Packed with plastic film.
Packed with plastic film and with PP woven bag.
Wooden pallet.
According to the customer request, fixed-length or heavy package.
Product Supply Form: Roll / Sheet or Plate / Strip
Get more information:
Email: info@chn-rubber.com
WhatsApp & P .H & Wechat: 008615222735180
SBR green rubber sheet is designed for general purpose use, a synthetic rubber known for its similarity to natural rubber in elasticity and wear resistance, often at a more attractive price. It performs well in applications requiring physical toughness and moderate temperature resistance, but has limited resistance to oils, fuels, ozone and strong chemicals. It is an excellent choice for general purpose applications where these specific resistances are not important. Its unique green color makes it easily identifiable for specific applications, color coding or simple aesthetic preference.
KEY FEATURES:
- Good durability and wear resistance: Resists friction, abrasion and general wear, suitable for use as a protective lining and impact absorption.
- Excellent impact strength: Helps cushion shock and protect the surface or equipment below.
- Good water resistance: Suitable for basic sealing applications to prevent water and moisture intrusion (not recommended for continuous immersion without specific testing).
- Flexibility: Remains flexible and easy to use, conforms to moderate curves and shapes.
- Cost-effective: Provides reliable SBR performance without the high cost of specialized elastomers.
- Vivid green color: Can be used for identification, safety marking or specific design requirements.
FLAME RETARDANT RUBBER PERFORMANCE & SPECIFICATIONS
| SBR RUBBER SHEET TECHNICAL PARAMETERS | |||||||
| Code | Specific Gravity | Hardness (+/-5) | Tensile Strength | Elongation at break | Colour | Finish Type | |
| g/cm³ | Shore A | Mpa | (min） % | ||||
| STANSDARD | ASTM D397 | ASTM D2240 | ASTM D412 | ASTM D412 | --- | --- | |
| ZXZRS20401S | 1.3+/-0.05 | 55 | 8 | 400 | Green, customized production according to demand | Smooth in both sides OR 1/2 With sides cloth OR 1 side With bonding layer OR 1 side With anti-slip texture | |
| ZXZRS20401S | 1.35+/-0.05 | 55 | 6-7 | 350 | |||
| ZXZRS20401S | 1.4+/-0.05 | 60 | 5-6 | 300 | |||
| ZXZRS20401S | 1.45+/-0.05 | 60 | 4-5 | 280 | |||
| ZXZRS20401S | 1.5+/-0.05 | 65 | 3-4 | 200 | |||
| ZXZRS20401S | 1.6+/-0.05 | 70 | 2.5-3 | 180 | |||
| ZXZRS20401S | 1.7+/-0.05 | 75 | 2-2.5 | 160 | |||
| ZXZRS20401S | 1.8+/-0.05 | 75 | 1.5 | --- | |||
| ZXZRS20401S | 1.9+/-0.05 | 80 | 1-1.5 | 100 | |||
| Note: 1MPa =10.2 Kg/cm² 1N/mm =1.02 Kg/cm | |||||||
| SPECIFICATION | ||||||||||||
| Thickness | Dimension | Insertion | Weight KGS/m² | |||||||||
| mm | m | Material | Layers | 1.3+/-0.05 | 1.35+/-0.05 | 1.4+/-0.05 | 1.45+/-0.05 | 1.5+/-0.05 | 1.6+/-0.05 | 1.7+/-0.05 | 1.8+/-0.05 | 1.9+/-0.05 |
| 1 | 1.2 x10 | Nylon canvas / Mesh fabric / Nylon mesh fabric / Encrypted canvas | / | 12.48 | 12.96 | 13.44 | 13.92 | 14.40 | 15.36 | 16.32 | 17.28 | 18.24 |
| 1.5 | 1.2 x10 | / | 20.28 | 21.06 | 21.84 | 22.62 | 23.40 | 24.96 | 26.52 | 28.08 | 29.64 | |
| 2 | 1.2 x10 | 1PLY | 28.08 | 29.16 | 30.24 | 31.32 | 32.40 | 34.56 | 36.72 | 38.88 | 41.04 | |
| 3 | 1.2 x10 | 1PLY | 43.68 | 45.36 | 47.04 | 48.72 | 50.40 | 53.76 | 57.12 | 60.48 | 63.84 | |
| 4 | 1.2 x10 | 1PLY | 59.28 | 61.56 | 63.84 | 66.12 | 68.40 | 72.96 | 77.52 | 82.08 | 86.64 | |
| 5 | 1.2 x10 | 2PLY | 74.88 | 77.76 | 80.64 | 83.52 | 86.40 | 92.16 | 97.92 | 103.68 | 109.44 | |
| 6 | 1.2 x10 | 3PLY | 90.48 | 93.96 | 97.44 | 100.92 | 104.40 | 111.36 | 118.32 | 125.28 | 132.24 | |
| 8 | 1.2 x10 | 4PLY | 121.68 | 126.36 | 131.04 | 135.72 | 140.40 | 149.76 | 159.12 | 168.48 | 177.84 | |
| 10 | 1.2 x10 | 5PLY | 152.88 | 158.76 | 164.64 | 170.52 | 176.40 | 188.16 | 199.92 | 211.68 | 223.44 | |
| 12 | 1.2 x10 | 8PLY | 184.08 | 191.16 | 198.24 | 205.32 | 212.40 | 226.56 | 240.72 | 254.88 | 269.04 | |
| 15 | 1.2 x10 | 10PLY | 230.88 | 239.76 | 248.64 | 257.52 | 266.40 | 284.16 | 301.92 | 319.68 | 337.44 | |
| 20 | 1x2 | ≥10PLY | 52 | 54 | 56 | 58 | 60.00 | 64 | 68 | 72 | 76 | |
| 25 | 1x2 | ≥10PLY | 65 | 67.5 | 70 | 72.5 | 75.00 | 80 | 85 | 90 | 95 | |
| 30 | 1x2 | ≥10PLY | 78 | 81 | 84 | 87 | 90.00 | 96 | 102 | 108 | 114 | |
| 50 | 1x2 | ≥10PLY | 130 | 135 | 140 | 145 | 150.00 | 160 | 170 | 180 | 190 | |
* Tabulated weight values are provided for informational purposes only. As dimensional specifications of rubber sheets are fully customizable per project requirements, actual weights may vary accordingly. For precise weight calculations tailored to your application, please submit specific technical parameters to our engineering team.
* Please ensure the product meets your application specification prior to order placement.
Insertion materials:
 |
 |
 |
 |
| Nylon canvas | Mesh fabric | Nylon mesh fabric | Encrypted canvas |
TARGET APPLICATIONS:
- 1. Cutting complex gaskets for low pressure seals (non-oil/solvent).
- 2. Creating thin protective padding inside drawers or tool boxes.
- 3. Worktop and protective surface padding.
- 4. Developing low profile anti-vibration pads.
- 5. Skirts and wipers
- 6. Floor protectors (light to moderate traffic)
- 7. DIY projects requiring a resilient rubber material
- 8. Making delicate components where minimum thickness is critical.
Whether you need a standard thickness or a rubber sheet thin enough for delicate tasks, our SBR green rubber sheet is a viable and reliable choice.
