The economical nitrile rubber roll provided by Tianjin China Rubber Co., Ltd is a widely used material with slight oil and solvent resistance. We use NBR plus other rubber compounds to produce it. It has certain resistance and can be used not only in oil and fuel resistant environments, but also in heat, transmission and waterproof environments. We can provide standard materials with a thickness of 1mm~100mm and a width of 1m~2m. We have both stock and can place orders (depending on the situation), and our maximum material width can reach 2m. If special applications, we can provide customized cutting services. The standard material of NBR rubber sheet is black, has certain elasticity, smooth on both sides, and has a glossy surface. We can also provide 1/2 With sides cloth OR 1 side With bonding layer OR 1 side With anti-slip texture, depending on the requirements of your application.

KEY FEATURES

• This 3mm nitrile rubber sheet is engineered with a consistent 1.7g/cm³ specific gravity, ensuring reliable durability in economical applications.
• It is suitable for environments with light oil contact, but in situations with large amounts of oil or long-term oil contact, materials with higher NBR content are required. Please consult sales for specific details.
• 3mm nitrile rubber sheet is available in three forms, rolls/sheets and cut into strips.
• Versatile product options available, including customized surface such as anti-slip textures or bonding layers to meet specific industrial requirements.

NITRILE RUBBER ROLL PERFORMANCE & SPECIFICATIONS

NBR ECONOMICAL RUBBER SHEET TECHNICAL PARAMETEERS
Specific Gravity	Hardness (+/-5)	Tensile Strength	Elongation at Break	Colour	Finish Type
g/cm³	Shore A	Mpa	(min) %	---	---
ASTM D397	ASTM D2240	ASTM D412	ASTM D412	---	---
1.7+/-0.05	65	3	230	Black	Smooth in both sides OR 1/2 With sides cloth OR 1 side With bonding layer OR 1 side With anti-slip texture
1.7+/-0.05	65	3	230	Red
1.7+/-0.05	65	3	230	White
1.7+/-0.05	65	3	230	Green
1.7+/-0.05	65	3	230	Blue
SPECIFICATION
Thickness	Width	Length	Insertion		Weight
mm	m	m	Materials	Layers	KGS/m²
1	Standard width	5m/10m/15m/20m	Nylon canvas / Mesh fabric / Nylon mesh fabric / Encrypted canvas	/	16.32
1.5	Standard width	5m/10m/15m/20m		/	26.52
1.7	Standard width	5m/10m/15m/20m		1PLY	30.6
2	Standard width	5m/10m/15m/20m		1PLY	36.72
3	Standard width	5m/10m/15m/20m		1PLY	57.12
4	Standard width	5m/10m/15m/20m		1PLY	77.52
5	Standard width	5m/10m/15m/20m		2PLY	97.92
6	Standard width	5m/10m/15m/20m		3PLY	118.32
8	Standard width	5m/10m/15m/20m		4PLY	159.12
10	Standard width	5m/10m/15m/20m		5PLY	199.92
12	Standard width	5m/10m/15m/20m		8PLY	240.72
15	Standard width	5m/10m/15m/20m		10PLY	301.92
20	Standard width	5m/10m/15m/20m		≥10PLY	68
25	Standard width	5m/10m/15m/20m		≥10PLY	85
30	Standard width	5m/10m/15m/20m		≥10PLY	102
50	Standard width	5m/10m/15m/20m		≥10PLY	175
*  Tabulated weight values are provided for informational purposes only. As dimensional specifications of rubber sheets are fully customizable per project requirements, actual weights may vary accordingly. For precise weight calculations tailored to your application, please submit specific technical parameters to our engineering team.

Insertion material：

Three categories according to oil resistance:

POTENTIAL APPLICATIONS INDUSTRIES

This economical 1.7 specific gravity 3mm nitrile rubber sheet is suitable for general industrial use in multiple industries due to its slightly oil-resistant properties, including:

1. 1. Automotive Manufacturing and Repair: Used for engine compartment sealing gaskets, protective pads in light oil pollution environments, anti-skid mats in workshops, etc.
2. 2. Machinery and Equipment Manufacturing: Can be used for equipment seals, light oil seals, pipe gaskets, and parts that have a certain tolerance to oil stains.
3. 3. Warehousing and Logistics: Suitable for warehouse floor mats and shelf liners for storing oils or chemicals to reduce the impact of spills on the ground.
4. 4. Food Processing and Packaging (non-direct food contact): Used for anti-skid floor mats in food factory production workshops and workbench mats in light oil pollution environments.
5. 5. Electronics and Electrical Industry: Used for equipment gaskets, electrical cabinet seals, and protective pads used in waterproof, dustproof, and light oil pollution-resistant working environments.
6. 6. Construction and Decoration: Used for waterproof layers, floor liners, and oil-proof and anti-skid areas in certain industrial sites.

This 3mm nitrile rubber sheet can provide basic protection and durability in industrial environments that require moderate oil and fuel resistance. It also has a high cost-effectiveness and is suitable for large-volume procurement and customized applications. Regarding nitrile rubber sheet price, please consult our professional sales staff.
