3Mpa black rubber sheet SBR material 60Shore A
3Mpa black rubber sheet SBR material 60Shore A 3Mpa black rubber sheet SBR material 60Shore A

3Mpa black rubber sheet SBR material 60Shore A

Product ID : ZXZRS20101S
Product Attributes :

Reference Standard: ASTM standard

Quality Certification: SGS RoHS2.0 REACH

Thickness: 3mm; Thickness over 15mm, available in sheet form

Specification (W/L):

Width: Standard 1mtrs 1.2mtrs 1.4mtrs 1.5mtrs 1.6mtrs 1.8mtrs 2.0mtrs

Length: Standard 5mtrs 10mtrs 15mtrs 20mtrs. Available upon request

Color: Black

Packing Information: Regular / Up to your choice

Packed with plastic film.

Packed with plastic film and with PP woven bag.

Wooden pallet.

According to the customer request, fixed-length or heavy package.

Product Supply Form: Roll / Sheet or Plate / Strip

sbr rubber sheet

Get more information:

Email: info@chn-rubber.com

P.H & Wechat: 008615222735180

Chat on WhatsApp

Product Description

Secure consistent quality, reliable supply, and expert support by sourcing your black rubber sheeting directly from Tianjin China Rubber Co.,Ltd, a dedicated manufacturer. We specialize in the production of high-performance black rubber sheets designed for a multitude of demanding industrial applications. By controlling the entire manufacturing process – from precise raw material compounding and mixing to calendering, curing, and final quality inspection – we ensure every sheet meets stringent standards and delivers dependable performance. Eliminate supply chain uncertainties and partner with the source for your critical black rubber requirements. Whether you need general-purpose sheeting or materials compounded for specific resistances, our manufacturing capabilities provide the foundation for your success.

Why Choose Black Rubber Sheeting from Tianjin China Rubber Co.,Ltd (Manufacturer Advantages):

  • Consistent Quality Assurance: Our direct manufacturing oversight guarantees rigorous adherence to material specifications and quality control protocols, ensuring predictable performance batch after batch.
  • Lot-to-Lot Uniformity: Controlled compounding and curing processes result in dependable physical properties (hardness, tensile strength, elongation) across every sheet we produce.
  • Reliable Supply & Lead Times: As the manufacturer, we offer greater control over production scheduling and inventory, providing more dependable lead times and supply chain stability.
  • Direct Technical Support: Access our in-depth knowledge of rubber compounding and manufacturing. We can assist with material selection and provide technical data to match your application needs.
  • Potential for Customization: Discuss specific requirements for thickness, width, or potentially adjusted compounds directly with the manufacturing source (subject to volume and feasibility).
  • Competitive Value: Sourcing directly often provides better value by minimizing intermediary costs, delivering high-quality materials efficiently.

BLACK RUBBER SHEET PERFORMANCE & SPECIFICATIONS

SBR RUBBER SHEET TECHNICAL PARAMETERS
Code Specific Gravity Hardness (+/-5) Tensile Strength Elongation at Break Colour Finish Type
g/cm³ Shore A Mpa (min) %
STANSDARD ASTM D397 ASTM D2240 ASTM D412 ASTM D412 --- ---
ZXZRS20101S 1.5+/-0.05 65 3-4 200 Black Smooth in both sides OR 1/2 With sides cloth OR 1 side With anti-slip texture
ZXZRS20201S 1.5+/-0.05 65 3-4 200 Red
ZXZRS20401S 1.5+/-0.05 65 3-4 200 Green
ZXZRS20001S 1.5+/-0.05 65 3-4 200 Customized production according to demand
Note: 1MPa =10.2 Kg/cm²  1N/mm =1.02 Kg/cm
SPECIFICATION
Item Thickness Width Length Insertion Weight
mm m m Material Layers KGS/m² lb/ft²
1 1 Standard width 5m/10m/15m/20m Nylon canvas / Mesh fabric / Nylon mesh fabric / Encrypted canvas / 14.40  2.95
2 1.5 Standard width 5m/10m/15m/20m / 23.40  4.79
3 1.7 Standard width 5m/10m/15m/20m 1PLY 27.00  5.53
4 2 Standard width 5m/10m/15m/20m 1PLY 32.40  6.64
5 3 Standard width 5m/10m/15m/20m 1PLY 50.40  10.32
6 4 Standard width 5m/10m/15m/20m 1PLY 68.40  14.01
7 5 Standard width 5m/10m/15m/20m 2PLY 86.40  17.69
8 6 Standard width 5m/10m/15m/20m 3PLY 104.40  21.38
9 8 Standard width 5m/10m/15m/20m 4PLY 140.40  28.75
10 10 Standard width 5m/10m/15m/20m 5PLY 176.40  36.13
11 12 Standard width 5m/10m/15m/20m 8PLY 212.40  43.50
12 15 Standard width 5m/10m/15m/20m 10PLY 266.40  54.56
13 20 Standard width 5m/10m/15m/20m ≥10PLY 60.00  12.29
14 25 Standard width 5m/10m/15m/20m ≥10PLY 75.00  15.36
15 30 Standard width 5m/10m/15m/20m ≥10PLY 90.00  18.43
16 50 Standard width 5m/10m/15m/20m ≥10PLY 150.00  30.72

* Tabulated weight values are provided for informational purposes only. As dimensional specifications of rubber sheets are fully customizable per project requirements, actual weights may vary accordingly. For precise weight calculations tailored to your application, please submit specific technical parameters to our engineering team.

Insertion materials:

viton gasket sheet viton gasket sheet viton gasket sheet viton gasket sheet
Nylon canvas Mesh fabric Nylon mesh fabric Encrypted canvas

black rubber sheet manufacturers

black rubber sheet manufacturers

Common Black Rubber Sheet Materials We Manufacture: (Customize this list based on your actual offerings)

  • SBR (Styrene-Butadiene Rubber): General-purpose, cost-effective sheeting with good abrasion and impact resistance.
  • Neoprene (Chloroprene Rubber): Versatile material offering moderate resistance to oil, ozone, and heat, known for its toughness.
  • EPDM (Ethylene Propylene Diene Monomer): Excellent resistance to weathering, ozone, UV, water, and steam; ideal for outdoor applications.
  • Nitrile (Acrylonitrile Butadiene Rubber): Superior resistance to oils, fuels, solvents, and hydraulic fluids.
  • (Other materials you produce in black, e.g., Natural Rubber blends, specific proprietary compounds)

TYPICAL APPLICATIONS

  • Gasket and Seal Fabrication
  • Industrial Lining (Chutes, Hoppers, Skirts)
  • Impact and Abrasion Protection Pads
  • Vibration Dampening Mounts and Isolators
  • Workshop Matting and Flooring Runners
  • Conveyor Belt Skirting
  • Flange Gaskets
  • Protective Barriers and Curtains
  • General Industrial Component Manufacturing
  • Ready to Partner with a Reliable Manufacturer?
  • Get the quality and consistency you need directly from the source.
