PRODUCT
High elasticity wear-resistant natural rubber sheeting
Reference Standard: ASTM standard
Quality Certification: SGS RoHS2.0 REACH
Thickness: 1mm-100mm; Thickness over 15mm, available in sheet form
Specification (W/L):
Width: Standard 1mtrs 1.2mtrs 1.4mtrs 1.5mtrs 1.6mtrs 1.8mtrs 2.0mtrs
Length: Standard 5mtrs 10mtrs 15mtrs 20mtrs. Available upon request
Color: Red/Black/Tan/Green; Customized production according to demand
Packing Information: Regular / Up to your choice
Packed with plastic film.
Packed with plastic film and with PP woven bag.
Wooden pallet.
According to the customer request, fixed-length or heavy package.
Product Supply Form: Roll / Sheet or Plate / Strip
Get more information:
Email: info@chn-rubber.com
WhatsApp & P .H & Wechat: 008615222735180
Natural rubber sheeting are a high-demand elastomer solution with SGS/RoHS2.0 and ASTM certification. This specialty grade product uses a high natural rubber content combined with other polymers and stabilizers to achieve adaptive performance in low to medium pressure environments. These sheets are precision calendered with thicknesses ranging from 1mm to 100mm and exhibit uniform density (±0.2mm tolerance) on standard 1m×2m formats or continuous 1.2m wide rolls. Ideally suited for static load scenarios, with tensile strengths ranging from 8Mpa to 20Mpa and elongations from 300% to 700% (ASTM D412), natural rubber sheeting provides durable coverage for workshop benches, conveyor skirts, and equipment liners. Custom die-cutting services enable precise gasket contours for sealing non-critical joints in HVAC and light industrial systems.
KEY FEATURES:
Surface versatility: Customizable smooth in both sides OR 1/2 With sides cloth OR 1 side With bonding layer OR 1 side With anti-slip texture, which can enhance anti-slip properties.
NR RUBBER SHEET PERFORMANCE & SPECIFICATIONS
| NR RUBBER SHEET TECHNICAL PARAMETERS | ||||||
| Code | Specific Gravity | Hardness (+/-5) | Tensile Strength | Elongation at break | Tear Strength | Resilience |
| g/cm³ | Shore A | Mpa | (min） % | N/mm | % | |
| STANSDARD | ASTM D397 | ASTM D2240 | ASTM D412 | ASTM D412 | --- | --- |
| ZXZRS20001N | 0.98+/-0.05 | 38 | 20 | 700 | 62 | --- |
| ZXZRS20001N | 1.2+/-0.05 | 45 | 14 | 500 | --- | --- |
| ZXZRS20001N | 1.25+/-0.05 | 50 | 10 | 380 | --- | --- |
| ZXZRS20001N | 1.3+/-0.05 | 55 | 6 | 300 | --- | --- |
| ZXZRS20001N | 1.05+/-0.05 | 38 | 20 | 600 | 30 | --- |
| Note: 1MPa =10.2 Kg/cm² 1N/mm =1.02 Kg/cm | ||||||
| SPECIFICATION | ||||||||
| Thickness | Dimension | Insertion | Weight KGS/m² | |||||
| mm | m | Material | Layers | 0.98+/-0.05 | 1.05+/-0.05 | 1.2+/-0.05 | 1.25+/-0.05 | 1.3+/-0.05 |
| 1 | 1.2 x10 | Nylon canvas / Mesh fabric / Nylon mesh fabric / Encrypted canvas | / | 9.41 | 10.08 | 11.52 | 12.00 | 12.48 |
| 1.5 | 1.2 x10 | / | 15.29 | 16.38 | 18.72 | 19.50 | 20.28 | |
| 2 | 1.2 x10 | 1PLY | 21.17 | 22.68 | 25.92 | 27.00 | 28.08 | |
| 3 | 1.2 x10 | 1PLY | 32.93 | 35.28 | 40.32 | 42.00 | 43.68 | |
| 4 | 1.2 x10 | 1PLY | 44.69 | 47.88 | 54.72 | 57.00 | 59.28 | |
| 5 | 1.2 x10 | 2PLY | 56.45 | 60.48 | 69.12 | 72.00 | 74.88 | |
| 6 | 1.2 x10 | 3PLY | 68.21 | 73.08 | 83.52 | 87.00 | 90.48 | |
| 8 | 1.2 x10 | 4PLY | 91.73 | 98.28 | 112.32 | 117.00 | 121.68 | |
| 10 | 1.2 x10 | 5PLY | 115.25 | 123.48 | 141.12 | 147.00 | 152.88 | |
| 12 | 1.2 x10 | 8PLY | 138.77 | 148.68 | 169.92 | 177.00 | 184.08 | |
| 15 | 1.2 x10 | 10PLY | 174.05 | 186.48 | 213.12 | 222.00 | 230.88 | |
| 20 | 1x2 | ≥10PLY | 39.20 | 42.00 | 48.00 | 50.00 | 52.00 | |
| 25 | 1x2 | ≥10PLY | 49.00 | 52.50 | 60.00 | 62.50 | 65.00 | |
| 30 | 1x2 | ≥10PLY | 58.80 | 63.00 | 72.00 | 75.00 | 78.00 | |
| 50 | 1x2 | ≥10PLY | 98.00 | 105.00 | 120.00 | 125.00 | 130.00 | |
* Tabulated weight values are provided for informational purposes only. As dimensional specifications of rubber sheets are fully customizable per project requirements, actual weights may vary accordingly. For precise weight calculations tailored to your application, please submit specific technical parameters to our engineering team.
* Please ensure the product meets your application specification prior to order placement.
Inseretion materials:
 |
 |
 |
 |
| Nylon canvas | Mesh fabric | Nylon mesh fabric | Encrypted canvas |
TARGETED APPLICATIONS
- 1. Automotive & Transportation: Used for gasket and sealing applications in vehicles. And provides vibration damping and anti-slip surfaces.
- 2. Applied in expansion joints, bridge bearings, and protective flooring. Acts as a cushioning layer in structural applications.
- 3.Manufacturing & Heavy Industry: Used as machine padding, conveyor belt covers, and protective linings And provides wear resistance in industrial environments.
- 4. Mining & Quarrying: Used for chute linings, conveyor belt skirting, and impact-resistant pads. And provides excellent elasticity and abrasion resistance.
- 6. Marine & Shipbuilding: Applied in dock fenders, anti-slip flooring, and hatch seals. And resistant to water and environmental exposure.
